Jixiao_PWM controllers
Features:
1.Build-in industrial micro controller.
2.Big LCD display, all adjustable parameter.
3.Fully 4-stage PWM charge management.
4.Build-in short-circuit protection, open-circuit protection, reverse protection, over-load protection.
5.Dual mosfet Reverse current protection ,low heat production.
Jixiao_PWM controllers
| Image | Product Name | Model | Dimension (MM) | Weight | Warranty |
|
PWM Controller 12/24V 10A |
PWM-10 | 145*80*40 | 0.2kg | 2 year |
|
PWM Controller 12/24V 20A |
PWM-20 | 145*80*40 | 0.2kg | 2 year |
|
PWM Controller 12/24V 30A | PWM-30 | 145*80*40 | 0.2kg | 2 year |
 |
PWM Controller 12/24V 30A/40A | JXP01/JXP02 | 164*103.5*47 | 0.39kg | 2 year |
 |
PWM Controller 12/24V 50A/60A | JXP06/JXP04 | 189.27*127.2*54 | 0.65kg | 2 year |
Application
Jixiao_PWM controllers has four protections, which are overload protection, short-circuit protection, over voltage protection, low voltage protection. The charge regulator is suitable for regulating solar modules.
