Xinpuguang@ Rigid Series - Polycrystalline Solar Module
Xinpuguang@ Rigid Series - Polycrystalline Solar Module
Xinpuguang@ Rigid Series - Polycrystalline Solar Module

Xinpuguang@ Rigid Series - Polycrystalline Solar Module

Framed Poly Solar Modules
Robust and reliable
The rear of the modules is sealed with a high-grade TPT.
The modules frame and the enclosed glass are securely attached to one another.
Junction box with connection cable and MC4 compatible connector
Highest long expectancy even under extreme climatic conditions

Specification

Pmax Dimension (Unit:mm) Size of cell Voc(V) Isc(A) Vmp(V) Imp(A) C-Eff
15W 350*360*17 156*17.33 21.60  0.92  18.00  0.83  15.41%
20W 470*350*25 156*22.28 21.60  1.22  18.00  1.11  15.98%
23W 645*285*25 125*31.2 21.60  1.41  18.00  1.28  16.38%
150W 1460*670*35 156*156 21.60  9.16  18.00  8.33  17.20%
300W 1960*992*50 156*156 44.40  8.18  36.50  7.67  17.20%



STC: Irradiance 1000W/m2, Temperature 25℃, AM=1.5
